SKU:WSAL21371
4G High Gain SMA Antenna for Outdoor Condition, 4G/3G/2G/LPWA Support, Waterproof, Magnetic Base
Regular price
1.214 Ft
Sale price
1.214 Ft
Regular price
0 Ft
Unit price
per
Sale
Sold out
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Kurzbeschreibung: 4G High Gain SMA Antenna For Outdoor Condition, 4G/3G/2G/LPWA Support, Waterproof, Magnetic Base
4G high gain SMA antenna for outdoor condition, 4G/3G/2G/LPWA support, waterproof, magnetic base
4G outdoor waterproof antenna
4G/3G/2G/LPWA support, high gain, with magnetic base
Specifications
| Network support | 4G/3G/2G/LPWA | Gain | 12DBI |
|---|---|---|---|
| Frequency range | 700~2700 MHz | Connector | SMA inner pin |
| Band width | 2300 MHz | Input power | 10W MAX |
| Output impedance | 50Ω | Antenna height | 32 cm |
| VSWR | ≤ 1.5 | Cable length | ~3m |
| Polarisation | Vertical | Color | Black |
| Waterproof | IP65 | Operating temp. | -40℃ ~ +85℃ |
Design details
4G antenna connection example
working with SIM7600G-H 4G DTU
for reference ONLY, the SIM7600G-H 4G DTU is not included.
Outline dimensions
Lieferumfang
- 4G/3G/2G/LPWA Outdoor Antenna x1
