SKU:WSAL21653
OV9281-110 Mono Camera for Raspberry Pi, Global Shutter, 1MP
Regular price
11.735 Ft
Sale price
11.735 Ft
Regular price
0 Ft
Unit price
per
Sale
Sold out
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Kurzbeschreibung: OV9281-110 Mono Camera For Raspberry Pi, Global Shutter, 1MP
OV9281-110 mono Camera for Raspberry Pi, Global Shutter, 1MP
OV9281-110 mono camera
1MP, Global Shutter, 110°FOV
Compatible with Raspberry Pi series boards
Device Support
Raspberry Pi series
Supports Pi 5 / 4B / 3B+ / 3A+ / Zero / Zero 2 W, and CM 3 / 3+ / 4 / 5 (extra adapter board required)
Specifications
| Sensor | OV9281 | CMOS size | 1/4 inch |
|---|---|---|---|
| CAMERA type | mono | Pixels | 1MP (1280 × 800) |
| SHUTTER | Global Shutter | Aperture | F2.2 |
| Distortion | < 1% | Field of view | 110°(D)/93°(H)/70°(V) |
| Focal length | 2.1mm | FOCUSING | manual |
Global shutter, more clear imaging
the global shutter eliminates jello-effect while shooting fast moving objects more suitable for high frame rate capturing
Working with Raspberry Pi
direct connect to Raspberry Pi different variants including 5/4B/3B+/3A+/3B/2B/B+/A+, and Raspberry Pi Zero / Zero 2 W series
* for reference only, the Raspberry Pi 5, Raspberry Pi 4B, and Raspberry Pi Zero 2W are NOT included, please purchase separately.
Outline dimensions
Selection Guide
| Partnumber | Type | Pixels | Aperture | Foal Length (mm) | Field of View | Distortion | Dimensions (mm) |
|---|---|---|---|---|---|---|---|
| OV9281-110 Camera | mono | 1MP | 2.2 | 2.1 | 110° | < 1% | 25×23.86 |
| OV9281-120 Camera | mono | 1MP | 2.5 | 3.15 | 120° | < 7.5% | 25×23.86 |
| OV9281-160 Camera | mono | 1MP | 2.35 | 3.15 | 160° | < 14.3% | 25×24 |
Lieferumfang
- OV9281-110 Camera x1
- 15-pin FFC (opposite sides contact) x1
- RPi Zero V1.3 Camera Cable ~15cm x1
