7/10.1 inch DVI Display Module for Raspberry Pi Pico, IPS panel, 1024×600 Pixel, DVI interface Communication

7/10.1 inch DVI Display Module for Pico

Comes with Raspberry Pi Pico C/C++ demo and resources

• Size7/10.1"
• Resolution1024×600
• Display PanelIPS
• Viewing Angle170°
• InterfaceDVI
• OSD MenuBrightness/Contrast

Features at a glance

• Adopts IPS panel, 1024×600 resolution*, with 170° viewing angle
• Adopts DVI interface for higher communication speed
• Based on the Raspberry Pi Pico with onboard 40PIN header
• Built in OSD menu for brightness/contrast adjustment
• Available in 7inch and 10.1inch display sizes
• Suitable for advertisement picture display and other application scenarios
• Comes with online development resources and manual (examples for Raspberry Pi Pico C/C++)

*Due to the memory limitation of RP2040, the picture resolution (Max) will be 400×240 if the color format is RGB565.

Version Options

7inch

10.1inch

Specifications

Operating voltage	5V
Resolution	1024×600 pixels
Communication Interface	DVI
DISPLAY PANEL	IPS
Display size	7inch: 154.21×85.92mm 10.1inch: 222.72×125.28mm
PIXEL SIZE	7inch: 0.1506×0.1432mm 10.1inch: 0.2175×0.2088mm

Raspberry Pi Pico Header Compatibility

Onboard Female Pin Header For Direct Attaching To Raspberry Pi Pico

Connect to Raspberry Pi Pico WH

Connect to RP2040-Plus

for reference only, the Pico and RP2040-Plus are NOT included

Pin definition

Interface Introduction

Product Show

Outline dimensions

Resources & Services

Wiki:www.waveshare.com/wiki/PICO-DVI-LCD

Selection guide

Part Number	Type	Display color	Pixels	Display size (mm)	Bus	Driver	Dimensions (mm)	Touch
Pico-LCD-0.96	IPS	65K	160×80	21.70×10.80	SPI	ST7735S	52.00×25.00
Pico-LCD-1.14	IPS	65K	240×135	24.91×14.86	SPI	ST7789	52.00×25.00
Pico-LCD-1.3	IPS	65K	240×240	23.40×23.40	SPI	ST7789	52.00×26.50
Pico-LCD-1.44	TFT	65K	128×128	25.50×26.50	SPI	ST7735S	52.00×26.50
Pico-LCD-1.8	TFT	65K	160×128	35.04×28.03	SPI	ST7735S	52.00×34.50
Pico-LCD-2	IPS	65K	320×240	40.80×30.60	SPI	ST7789VW	52.00×35.00
Pico-ResTouch-LCD-2.8	IPS	262K	320×240	57.60×43.20	SPI	ST7789	70.20×50.20	√
Pico-ResTouch-LCD-3.5	IPS	65K	480×320	73.44×48.96	SPI	ILI9488	86.00×57.20	√
PICO-DVI-7inch	IPS	262K	1024×600	154.21×85.92	DVI	-	164.70×100.00
PICO-DVI-10.1inch	IPS	262K	1024×600	222.72×125.28	DVI	-	232.72×136.28

Lieferumfang

PICO-DVI-7inch

PICO-DVI-7inch x1

PICO-DVI-10.1inch

PICO-DVI-10.1inch x1
