IMX296 1.6MP M12 Mono Camera, Global Shutter, Supports Raspberry Pi Series Boards

IMX296 global shutter camera module

IMX296 Sensor | 1.6MP | Mono camera | Supports raspberry pi series boards

Features at a glance

This IMX296 mono global shutter camera module is based on the IMX296 sensor with 1.6MP resolution. It is capable of capturing fast moving objects without Jelly-Effect of rolling shutter, ideal for fast motion photography and machine vision applications. Adopts M12 lens offering 130° FOV, comes with dual FFC cables, compatible with all Raspberry Pi series boards.

Specifications

Sensor	Model	IMX296
	Resolution	1.58 MP (mono), 1456 × 1088
	CMOS diagonal size	6.3mm
	Pixel size	3.45µm × 3.45µm
Lens	Aperture (F)	1.6
	Back Focal Length (BFL)	3.0mm
	Field of View (FOV)	130° (D) 99° (H) 72° (V)
	Distortion	<20%

Global shutter, more clear imaging

the global shutter eliminates jelly-effect while shooting fast moving objects,more suitable for high-speed motion capturing

Working with Raspberry Pi

Connecting with Raspberry Pi 4B

Connecting with Raspberry Pi 5

Connecting with Raspberry Pi Zero 2 W

* for reference only, the Raspberry Pi 4B,Raspberry Pi 5,Zero 2 W are NOT included.

Outline Dimensions

Resources & Services

Wiki:www.waveshare.com/wiki/IMX296-130_BW_Camera

Selection Guide

Part Number	Pixels	Sensor	CMOS Size	IR-CUT Filter	Lens Support	FoV (°)	Aper-ture (F)	Focal Length (mm)	Dimen-sions (mm)	For use with
Raspberry Pi HQ Camera	12.3MP	IMX477	7.9mm	integrated	C/CS	-	-	-	38*38	Raspberry Pi, CM3/3+/4/5
IMX477 12.3MP Camera						-	-	-	38*38	Raspberry Pi, CM3/3+/4, Jetson series boards
Raspberry Pi HQ Camera M12					M12	-	-	-	38*38	Raspberry Pi, CM3/3+/4/5
IMX477 IR-CUT Camera (A)						90	2.0	3.95	38*38	Raspberry Pi, CM3/3+/4/5, Jetson series boards
IMX477-160 12.3MP Camera						160	2.2	2.75	25*24	Raspberry Pi, CM3/3+/4/5, Jetson series boards
Raspberry Pi Global Shutter Camera	1.6MP	IMX296	6.3mm		C/CS	-	-	-	38*38	Raspberry Pi, CM3/3+/4/5
IMX296 Global Camera (A)	1.6MP	IMX296	6.3mm		C/CS	-	-	-	38*38	Raspberry Pi, CM3/3+/4/5
IMX296-130 BW Camera	1.6MP	IMX296	6.3mm		M12	130	1.6	3.0	38*38	Raspberry Pi, CM3/3+/4/5

Lieferumfang

1. IMX296-130 BW Camera x1
2. 22PIN to 15PIN cable x1
3. 15PIN cable x1

1

2

3
