PCIe To 2-Ch SATA Adapter For Raspberry Pi 5, Supports SATA Hard Drive Protocol, Onboard Dual LED Indicators And EEPROM, HAT + Standard, Driver-free, Plug And Play

PCIe TO 2-CH SATA HAT+

Designed For Raspberry Pi 5, driver-free, plug and play

Connecting to Pi 5 via 16PIN Cable

Based on 16PIN PCIe Interface of Raspberry Pi 5

* for reference only, the Raspberry Pi 5 is not included

SATA Hard Drive Protocol

Dual-channel SATA interfaces, compliant with SATA Gen3 standard

PCIe to 2-ch High-Speed SATA 3.0

Compliant with SATA 3.0 (SATA Gen3) and PCIe Gen2 standards

* for reference only, please refer to the Package Content for the detailed part list.

SATA Drive Slot Support

* Only supports SATA protocol hard drives.

Onboard Dual LED Indicators

Easy to monitor the Working Status

Onboard EEPROM

For saving HAT ID and product information

Outline dimensions
