SKU:WSAL31454
PCIe To USB 3.2 Gen1 / 2.5G ETH / M.2 NVMe Adapter For Raspberry Pi 5, Supports NVMe Protocol M.2 Solid State Drive, Expands 2-ch USB 3.2 Ports And 2-ch Ethernet Ports
Abholverfügbarkeit konnte nicht geladen werden
Designed For Raspberry Pi 5, driver-free, plug and play
Dual 2.5G Ethernet Ports | Dual USB 3.2 Ports | M.2 NVMe Slot
Based on 16PIN PCIe Interface of Raspberry Pi 5
* for reference only, the Raspberry Pi 5 is not included
Compatible With 2230 / 2242 / 2260 / 2280 Size M.2 Solid State Drive Supports Gen2 Mode, Supports Booting PI5 From Solid State Drive
* Only supports the NVMe Protocol Solid State Drives.
Extends The PCIe Interface To 2-ch High-Speed USB 3.2 Gen1 Ports for connecting more peripherals
Onboard RTL8156B high-performance Gigabit ETH chip, sinking design of network port, neat and beautiful
* for reference only, the Raspberry Pi 5 is not included
Faster reading/writing speed compared to the TF card slot of Raspberry Pi, greatly improving reading/writing efficiency of the system or files, Supports booting Pi5 from NVME Solid State Drive
* for reference only, the Raspberry Pi 5 and Solid State Drive are not included.
Easy to monitor the Working Status
Real-time monitoring of Solid State Drive power status for More Stable operation
Attach the thermal tapes first, then install the Official Active Cooler and fix the HAT
Lieferumfang
- PCIe TO M.2 USB ETH HAT+ × 1
- 16PIN PCIe cable × 1
- Screws pack × 1
