SC132GS Binocular Stereo Camera Module, Global Shutter, 157° DFoV, Dual 1.3MP Cameras, Suitable For RDK X5
RDK binocular Stereo camera module
SC132GS | 1.3MP | Hardware Synchronization | 157° DFoV | Global shutter
Features
This product is a stereo depth camera based on the dual SC132GS global shutter sensors with onboard MIPI interfaces, supports synchronized dual exposure and external trigger operation. The module features an 80 mm baseline and delivers a maximum output frame rate of 120 fps. It provides high dynamic range (HDR) performance with a 40 dB SNR, features 1280 × 1080 resolution per channel and enhanced sensitivity in the 850 nm / 940 nm near-infrared (NIR) bands. It is suitable for applications such as robot vision, machine vision inspection, and real-time motion monitoring.
Specifications
| Pixels | 1.3MP | |
|---|---|---|
| sensor chip | SC132GS | |
| Camera | sensor size | 1/4 inch |
| Aperture (F) | 2.0 | |
| Resolution | 1280 × 1080 (per camera) | |
| Focal length (BFL) | 1.75mm | |
| Field of View (FOV) | 157.2°(D) 96.8°(H) 115.6°(V) | |
| Max frame rate | 120FPS | |
| Signal-to-noise ratio (SNR) | 40dB | |
| Baseline length | 80mm | |
| Synchronization | Supports external triggering and synchronization | |
| Operating temperature | -20°C ~ 60°C | |
Outline dimensions
Resources & Services
Lieferumfang
- RDK Stereo Camera Module GS130W x1
- 22PIN cable ~100mm x2
