SKU:WSAL29333

Wireless BE200 NIC, Gigabit Tri-Band Wi-Fi 7, IEEE 802.11a/b/g/n/ac/be/ax Standard, Bluetooth 5.4

Wi-Fi 7 Wireless BE200 NIC

Tri-Band

Bluetooth 5.4

MU-MIMO

Features at a glance

• Adopts the 7th generation wireless protocol, supports IEEE 802.11a/b/g/n/ac/be/ax wireless standard
• Supports WPA4 for privacy and data security
• Supports 2.4G/5G/6GHz tri-band, the speed up to 574Mbps in the 2.4GHz band, 2400Mbps in the 5GHz band and 5800Mbps in the 6GHz band
• Support Bluetooth 5.4 standard, longer transmission distance and better stability
• Adopts NGFF (M.2 E Key) interface
• Supports MU-MIMO technology for low-latency connections with multiple devices
• Support Linux, Windows 10/11, etc.
• AMD motherboards not supported

Parameters Comparison

Model	AX210			AX200		BE200
Wi-Fi Version	Wi-Fi 6E			Wi-Fi 6		Wi-Fi 7
Wi-Fi Band	2.4GHz	5GHz	6GHz	2.4GHz	5GHz	2.4GHz	5GHz	6GHz
Wi-Fi Rate	574Mbps	2400Mbps	2400Mbps	574Mbps	2400Mbps	574Mbps	2400Mbps	5800Mbps
Interface	NGFF (M.2 A/E Key)					NGFF (M.2 E Key)
Bluetooth Version	5.3			5.2		5.4
Technical Support	MU-MIMO
Antenna Connector	IPEX-4 Connector
System Support	Linux, Windows 10/11
Dimensions	22.0 × 30.0 × 2.4mm

BE200 High Performance Wi-Fi 7

Inherits the excellent performance of the AX210 and features optimized upgrades, offering you an exceptional Wi-Fi 7 experience

Tri-Band Wi-Fi

Supports 2.4G/5G/6GHz tri-Band, the speed up to 574Mbps in the 2.4GHz band, 2400Mbps in the 5GHz band and 5800Mbps in the 6GHz band

Bluetooth 5.4, More Stable Connection

It supports Longer Transmission Distance And Better Stability, Can Be Connected To Bluetooth Devices Such As Mobile Phones, Computers, Gamepad, Etc. For Wireless Connection And Transmission

* for reference only, the above controller boards or hosts are NOT included.

Supports MU-MIMO Technology

Supports simultaneous connections of multiple devices, reducing latency and increasing speed

WPA4 for privacy and data security

Supports WPA4 encryption technology, providing enhanced network security

Interface Introduction

Outline dimensions

Resources & Services

Wiki:www.waveshare.com/wiki/Wireless-BE200

Lieferumfang

1. Wireless-BE200 x1
2. IPEX to SMA cable ~20cm x2
3. Antenna x2
